Rated  power

                   3200W

                5000W

Rated  capacity

3KWh

5.12 KWh

PV parameters

Working  model

MPPT

Rated PV input voltage

36 0VDC

MPPT tracking voltage  range

120 - 450V

Max input voltage

( VOC ) at lowest temperature

500V

Max input power

4000W

6000W

Number of MPPT tracking

Paths

1Path

Input

DC input voltage  range

      21 - 30VDC

           42 - 60VDC

Rated  mains power input       voltage

                   220 / 230 / 240VAC

Grid power input voltage        range

170 ~ 280VAC ( UPS model) / 120 ~ 280 VAC         ( inverter model)

Grid input frequency range

40 ~ 55 H z ( 50 H z ) or 55 ~ 65 Hz ( 60 Hz )

Output

Inverter

Output          efficiency

                                 94%

Output          voltage

220VAC±2%/230VAC±2%/240VAC±2%

Output            frequency

                       50Hz±0.5or60Hz±0.5

Mains power

Output          efficiency

                                  ≥99%

Output          voltage range

                           Follow input

Output            frequency       range

                           Follow input

No-load loss in battery mode

                        ≤1%(rated power)

Mains mode no-load loss

0.5% rated power (mains charger does not work)

Battery

Battery

type

Lead acid      battery

Equalizing charging 13.8V Floating charging 13 .7V ( single battery voltage )

Custom         battery

Different types of battery charging and discharging parameters can be customized according to user requirements (different types of batteries can also be set through the operation panel)

Maximum PV input current

                                60A

Maximum photovoltaic           charging current

                                80A

Maximum mains charging      current

                                 80A

Charging method

Three-stage type (constant current, constant voltage, float charge)

Battery voltage alarm

           Factory default setting: 44V

Battery voltage protection

           Factory default setting: 42V

Battery over-voltage alarm

                               61VDC

Overload power protection

Automatic protection (battery mode), circuit breaker or fuse (mains mode)

Inverter output short circuit    protection

Automatic protection (battery mode), circuit breaker or fuse (mains mode)

temperature protection

                 ≥90℃ turns off the output

Performance parameters

conversion time

                                ≤4ms

Heat dissipation method

                      Intelligent cooling fan

Working environment               temperature

                            -10~40℃

storage temperature

                             -15~60℃

Altitude

                                2000m

relative humidity

                                0~95%

Product size

5 0 0 * 3 0 0 * 3 4 0 m m

5 0 0 * 3 0 0 * 3 4 0 m m

Packing size

6 0 0 * 4 0 0 * 4 4 0 m m

6 0 0 * 4 0 0 * 4 4 0 m m

Net weight

4 2 k g

5 5 k g

Gross weight

4 8 k g

6 5 k g
