Product specifications

48V100Ah

51.2V100Ah

Combination method

15S1P

16S1P

Battery pack capacity

4.8KWh

5.12KWh

Standard discharge current

50A

50A

Maximum discharge           current

100A

100A

Operating voltage range

40.5-54VDC

43.2-57.6VDC

Standard voltage

48VDC

51.2VDC

Maximum charging            current

50A

Maximum charging            voltage

54V

57.6V

Discharge depth and life

80%/25℃/0.5C/6000 cycles, energy retention rate ≥80%

Working humidity

65±20%RH

Operating temperature

0~+40℃

Working altitude

≤2500m

Firefighting

PACK 12g Aerosol

Cooling method

Natural cooling

Installation method

Standalone installation

Communication method

RS485/RS232/CAN optional WiFi/4G/Bluetooth

Warranty

5~10 years

Protection level

IP20

Product certification

CEROHS FCC UN38.3 MSDS ISO9001

Product size

450*550*195mm

Packing size

510*610*260mm

net weight

50kg

53kg

Gross weight

55kg

58kg
