Product specifications

5.12KWh/5KW

10.24KWh/5KW

15.36KWh/5KW

20.48KWh/5KW

Standard discharge

             current

50A

50A

50A

50A

Maximum discharge

             current

100A

100A

100A

100A

Operating voltage range

43.2-57.6VDC

43.2-57.6VDC

43.2-57.6VDC

43.2-57.6VDC

Standard voltage

51.2VDC

51.2VDC

51.2VDC

51.2VDC

Maximum charging

              current

50A

50A

50A

50A

Maximum charging        voltage

57.6V

57.6V

57.6V

57.6V

     Rated photovoltaic         input voltage

360VDC

        MPPT tracking          voltage range

120V-450V

Maximum photovoltaic  input voltage Voc

500V

Maximum photovoltaic  input power

6000W

MPPT tracking number of channels (number of  input channels

1 way

DC input voltage range

42-60VDC

      Rated mains

      input  voltage

220VAC/230VAC/240VAC

    Mains power input        voltage range

170VAC~280VAC (UPS mode) / 120VAC~280VAC (INV mode

   Mains power input         frequency range

45Hz~55Hz (50Hz); 55Hz~65Hz (60Hz)

         Inverter output          efficiency

94%(peak)

Inverter output voltage

220VAC±2%/230VAC±2%/240VAC±2%

          Inverter output         frequency

50Hz±0.5or60Hz±0.5

             Inverter output      waveform

pure sine wave

   Mains power output       efficiency

>99%

      Maximum mains       charging current

60A

Maximum photovoltaic charging current

100A

Maximum charging current (mains + photovoltaic)

100A

Optional mode

Mains power priority/photovoltaic priority/battery priority
