Product              specifications

 96V100AH

144V100AH

192V100AH

240V100AH

384V100AH

512V100AH

768V100AH

  Battery pack         capacity

9.6KWh

14.4KWh

19.2KWh

24KWh

38.4KWh

51.2KWh

76.8KWh

       Standard               discharge current

50A~300A (customized according to customer needs)

        Maximum                discharging             current

50A~300A (customized according to customer needs)

Operating voltage   range

81-108VDC

121.5-162VDC

121.5-216VDC

202.5-270VDC

324-432VDC

432-576VDC

648-864VDC

Standard voltage

96V

144V

192V

240V

384v

512V

768V

Maximum charging current

                        100A~200A (customized according to customer needs)

Maximum charging voltage

                                                               81~864V

Discharge depth and life

                       80%/25℃/0.5C/6000 cycles, energy retention rate ≥80%

Working humidity

65±20%RH

      Operating          temperature

0~+40℃

Working altitude

≤2500m

Cooling method

Natural cooling

Installation method

                    Cabinet/rack/stack installation

Communication     method

RS485/RS232/CAN optional WiFi/4G/Bluetooth

Warranty

5~10 years

Protection level

IP20

Product certification

CEROHS FCC UN38.3 MSDS ISO9001
